Warning: This Part Requires General Mechanical Abilities If you are not confident in your abilities
Please have this product installed at a Local Off-Road Shop .
Step 1:
Take an inventory of your parts, If you are
missing any parts Please contact Artec Industries Immediately @ (855)
278-3299 M-F 8:30am-5pm MST if it is
after those hours please email us pictures of what you received , along with
product labels on the box and packing slip at Sales@artecindustries.com
Step 2:
Lay out all of the parts You
will take Part 9 and flip it over so the part number is facing down. Insert part number 14 in the slot in the corresponding slot and slip part number
13 in the slot on the other slot the tabs and key ways are specific so it will
only fit one way. Now insert part 15
into the groove on the part 13/14 brackets
there will be a small rounded relief that will sit on the coil
indentation . Tack weld the brackets
into place .
Step 3 :
Continue Step 2 Process on the brackets for the opposite side.
Step 4:
Flip over the coil mounts. Using
your shock run a bolt through the coil bracket and the # 12 ( or #4) bracket
depending on what coil bucket you are working on to set the shock mounting
width . Tack weld the tab for the shock
mount into place and remove the shock.
Step 5:
Place pieces 10 and 11 on bracket 9 . Place your coil spring on piece 9
in the stamped coil relief and use the spring to center pieces 10 and 11. Remove
the spring and tack weld all pieces together.
Repeat this process for the other
side.
Step 6:
Fully weld the brackets together .
You should have 2 tabs left ( Part # 16 and 8) save those for later .
Step 7:
Weld the coil buckets onto your axle in the desired position for your
build . Now take the number 16
bracket and places it at the front of
the coil brackets in between the 13 and 14 the 16 bracket should be contacting
the axle tube and weld it into place you
will repeat this process for the other side also. After they are welded prime and paint the
parts and your job is complete .
Install videos are coming soon.
These coil buckets are perfect for the average TJ fabricator The coils LCA brackets and shock mounts line up perfectly and the extra thick brackets provide the much-needed strength for my 34 ton build. Keep in mind that the TJ dana 44 tube width is only 2.5 (not 3) and 68-72 Ford dana 44 tubes are only 2.75 but the majority of the other Ford 44s are 3.
I bought this item because I liked the stamped coil indention. That part is great but the shock mounts have too many small parts to weld that are unnecessary. The control arm brackets are nice but be prepared to use the grinder to get them to fit flat and straight on your axle. I dont like the coil centering piece its bent flat stock and doesnt look good. Of all the cool stuff and fantastic fab stuff why flat stock All the parts had to be modified to fit
Everything Is cut cleanly & accurately. Very well thought out. Would very much recommend Artec to anyone.
I used these to swap a high pinion Dana 44 in my lj they work and look awesome I will only use Artec brackets
AWESOME PRODUCT great design plenty of beef parts are tabbed for easy install look way cooler than any other product I could find should fit most jeep coil springs (fits XJ springs fit for sure)
