Product Details
- OEM 2.4" mounting width fits common sized cartridge joints and factory control arm bushings
- Designed to not interfere with joint movement
- Secured to axle better than OEM so it doesn’t rip off
- 1/4" thick steel
- Boxed plate for strength and impact resistance
- Sold in a pair
- Made in the USA
- *The JK4430 is specifically made for the JKU Rock Krawler Rear Upper Control Arm
Install Instructions
ArtecIndustries ◢
Install guides are coming soon.
ArtecIndustries ◢
Install videos are coming soon.
Reviews
Q
Anonymous
Will this work with the apex truss?
A — Staff (Artec Team): Yes it can be used in conjunction with the apex truss .
Mar 2, 2022
Q
Anonymous
Hi, Will the jk rear 3 link bracket JK4430 work with some modifications on the jk apex rear truss? I already have the apex rear truss on my axle. thanks, Matt
A — Staff (Artec Team): Yes this will work with the apex truss but it may hang off of the back a hair. You will have to slightly trim the ends of the gussets to fit the apex truss.
Feb 3, 2021
Q
Anonymous
Will this work with your 60 modular rear truss?
A — Staff (Artec Team): Yes this will work with all of our rear truss's for a JK with a 1ton rear you will need to possibly trim 1-1.5" off of the bottom of the bracket due to the taller housing .
Nov 30, 2020
Q
Anonymous
Hi, will the jk rear 3-kink bracket JK4430 work with your UD60 Rear Apex short truss JK4430? Thank you
A — Staff (Artec Team): Yes it will work with the apex truss's
Nov 26, 2020
Q
Anonymous
Will this fit on a apex truss.
A — Staff (Artec Team): Yes, this bracket will fit on the rear apex truss
Jul 19, 2020
Q
Anonymous
Does this work with the new Apex truss?
A — Staff (Artec Team): Yes this will work with the apex truss but it may hang off of the back a hair .
Apr 17, 2020
